2 of 5, Drawing 2 of 5 - case assembly – Castle TSM-35 Serial 60343 and lower Assembly Drawing & Parts User Manual
Page 4
Item #
Part #
Part Description
Qty
Item #
Part #
Part Description
Qty
1
C35010
Top Assembly - See Page 2.
1
8
Router Drive Speed Control
P00117
Valve, Flow Control, SMC NAS-2000-N01
1
2
Control Panel Assembly - See Page 5.
1
P18165
Fitting, 1/8 NPT x 1/16 Side Out Barb, Brass
1
P18161
Fitting, 1/8 NPT x 1/16 Barb, White Nylon
1
3
C35002
TSM-35 FRL Assembly
F08112
Screw, Pan Phillips, 8-32 x 1-1/2 ZP
2
P35066
TSM-35 Filter/Regulator, Parker
1
F08032
Nut, Nylon Lock 8-32
2
P35067
TSM-35 Lubricator, Parker
1
P35068
TSM-35 FRL Mount Bracket
1
9
Main Case
P35069
TSM-35 FRL Connector
1
M35001
Main Case, Green
1
P35070
TSM-35 Gauge
1
S00320
Label, Serial Number
1
P14414
1/4 Male x 1/4 Pl Elbow
1
F14212
Carriage Bolt, 1/4-20 x 1/2 ZP
2
P21244
1/4 NPT x 3/8 Pl Elbow Norgren
1
F03810
Washer, 3/8 SAE ZP
2
P26482
1/8M x 1/4 Pl Straight Alkon
1
F14340
Carriage Bolt, 1/4-20 x 3/4 ZP
6
P14116
1/4 Male Street L Brass
1
F01410
Washer, 1/4 SAE ZP
6
F01420
Nut, Nylon Lock, 1/4-20 ZP
8
4
M00400
Door, Front, Black w/ Logo
1
F08012
Screw, Pan Phillips Machine, 8-32 x 1/2 ZP
7
F08032
Nut, Nylon Lock, 8-32 ZP
7
5
Door Handle Assembly
D08320
Cable Tie Holder, Small White Nylon
5
H00141
Bar Knob, Plastic, 1/4-20
1
N00101
Spring Door Clip
1
10
Air Reservoir Assembly
F14125
Screw, Hex Head Cap, 1/4-20 x 1/2 ZP
1
M35624
Air Manifold, Black 6" OD x 24" L
1
S00161
Strap, Manifold Retaining
2
6
Door Hinge Assembly
2
F14585
Screw, Hex Head Cap, 14/-20 x 5/8 ZP
4
D00402
Hinge, Plastic, Black, Female
2
F14225
Screw, Hex Head Cap, 1/4-20 x 1 ZP
1
F10241
Screw, Pan Head Phillips, 10-24 x 1/4 ZP
4
F01410
Washer, 1/4 SAE ZP
5
F01422
Nut, Lock Washer 1/4-20 Kep ZP
5
7
Case Hinge Assembly
2
P03838
Fitting, 3/8 NPT x 3/8 Push In Straight
1
D00401
Hinge, Plastic, Black, Male
2
P38012
Tube, 3/8 OD Black Polyethelene
1.0"
F10241
Screw, Pan Head Phillips, 10-24 x 1/4 ZP
4
P38012
Tube, 3/8 OD Black Polyethelene
20.5"
P50638
Check Valve, 3/8 x 3/8 In Line, Norgren
1
P01403
Pipe Connector, 1/4 NPT Brass T
1
P14438
Fitting, 1/4 NPT x 3/8 Push In Elbow
1
P14002
Drain Cock, 1/4 NPT Type 2
1
P14214
Nipple, 1/4 NPT Hex Close
1
Drawing 2 of 5 - Case Assembly
