5 of 5 (2), Drawing 5 of 5 - control panel assembly – Castle TSM-35 Serial 60343 and lower Assembly Drawing & Parts User Manual
Page 12
Item #
Part #
Part Description
Qty
Item #
Part #
Part Description
Qty
14
Starter Assembly
15
Pneumatic Control Assembly ( Continued )
E91024
Contactor, S&S CA4-9-10 24VDC
1
Drill Valve
F08012
Screw, Pan Phillips Machine, 8-32 x 1/2 ZP
2
P41024
Valve, 4-Way, Humphrey 410 24VDC
1
F08132
Nut, Lock Washer, 8-32 Kep ZP
2
P18532
Fitting, 1/8NPT x 5/32 Barb Blk Nylon
1
E14316
Wire, 16AWG Stranded x 14"
3
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
2"
E18379
Wire, 18AWG Hookup White
7.5"
P53233
Fitting. 5/32 T Barb, Black Nylon
1
E91827
Motor Overload,S&S CT4-9 1.8-2.7(460V)HI
1
P18162
Fitting, 1/8NPT x 1/8 Barb Black Nylon
1
OR
P16182
Tubing, 1/8 OD x 1/16 ID Black Urethane
31"
E94060
Motor Overload,S&S CT4-9 4.0-6.0(208/230V)LO
1
P53202
Tubing, 5/32 OD x 3/32 ID, Black Urethane
30"
P33216
Fitting, 3/32 x 1/16 T Barb, Black Nylon
1
15
Pneumatic Control Assembly
P53202
Tubing, 5/32 OD x 3/32 ID, Black Urethane
40"
Clamp Valve
Control Valve Assembly
P31024
Valve, 3-Way, Humphrey 310 24VDC
1
F63230
Screw, Pan Phillips Machine, 6-32 x 3" ZP
2
P18532
Fitting, 1/8NPT x 5/32 Barb Blk Nylon
2
F63201
Nut, Nylon Lock, 6-32 ZP
2
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
2"
P53233
Fitting. 5/32 T Barb, Black Nylon
1
Harness Assembly
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
3"
S12043
Spiral Wrap. 1/2" Black Polyethelene
22"
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
71"
D40000
Cable Tie, White Nylon, 4"
22
D51213
Cable Tie, White Nylon, 5-1/2"
1
Router Valve
P41024
Valve, 4-Way, Humphrey 410 24VDC
1
16
Security Switch Assembly
P18532
Fitting, 1/8NPT x 5/32 Barb Blk Nylon
1
E35001
Switch,Security Interlock,TelemechaniqueXCSPA593
1
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
1"
H12516
Grommet, Black Rubber, 5/16 ID x 1/2 OD
1
P53233
Fitting. 5/32 T Barb, Black Nylon
1
E18202
Wire, 18-2 SJT, 2-Wire, Fully Insulated
25"
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
3.5"
P14170
Tubing, 1/4 OD x .170 ID, Black Polyurethane
17"
17
Foot Switch Assembly
P18161
Fitting, 1/8NPT x 1/16 Barb, White Nylon
1
E00491
Switch,Foot Activated,Linemaster491-36SC w/Cord
1
P16181
Tubing, 1/8 OD x 1/16 ID White Urethane
31"
M00235
Guard, Universal Footswitch
1
P00532
Fitting, 1/8NPT x 5/32 Push In Straight
1
F40388
Screw, Oval Head Self-Tapping, #4 x 3/8 SS
2
P53202
Tubing, 5/32 OD Clear - See 4 of 5 #19 Page 7
Drawing 5 of 5 - Control Panel Assembly
