Thermocouples - Nozzle and Pipe Clamp

L3

Le

n

g

th

Inside

Diameter

Lead

Length

3

/

16

”

1) Series

145

146

2) Bolt Sizes

A =

1

/

4

x 28 UNF, B = 8-32, C = 10-32,

D = M6 x 1

Band

E =

11

/

16

-1

1

/

4,

F = 1

1

/

4

-2

1

/

4,

diameters

G = 2

1

/

4

-3

1

/

4,

H = 3

1

/

4

-4

1

/

4,

I = 4-5, J = 5-6, K = 6-7,

3) Calibration

J,

K,

T,

E

4) Junction

G = Grounded,

U = Ungrounded

5) Leads

T = Fiberglass 24 ga stainless braid

S = Fiberglass 20 ga stainless braid

I = Fiberglass 24 ga stainless hose

H = Fiberglass 20 ga stainless hose

A = Teflon 24 ga

B = Teflon 20 ga

6) Lead length

In whole inches 006-999

7) Termination

Choose a terminal design from pg L8

8) Special options Enter 0 if none. Specify others at

time of order

Ordering Code

1

6

5

4

3

2

7

8

Figure 355

Figure 356

Series 145

Series 146
