9 AP-7000 SERIES LEG PRESS STATION
Assembly List
Item #
Description
Qty
.
8
CROSS BRACE
1
9
DOUBLE PULLEY
BRACKET (4 1/2 PULLEYS)
2
12
HANDLES
1
20
SIDE FRAME
1
26
REINFORCEMENT PLA
TE 1/4 X 2 X 5 (3/8-16 TPI HLS)
1
38
BUTT
ON HEAD SCREW GR-8 N/P
3/8-16 X 1
2
41
BUTT
ON HEAD SCREW GR-8 N/P
3/8-16 X 2
2
43
BUTT
ON HEAD SCREW GR-8 N/P
3/8-16 X 3
2
53
FLA
T
W
ASHER SAE N/P
3/8”
10
57
BUTT
ON HEAD SCREW GR-8 N/P
3/8-16 X 2 3/4
2
56
FLA
T
W
ASHER N/P
3/8 ID X 1 1/2 OD X 3/16
2
60
NYLON INSER
T
LOCK NUT
N/P
3/8-16
4
61
NYLON PULLEY
3/8 X 1 X 4 1/2 BLACK
2
74
SOCKET
CAP
SCREW GR-8 N/P
3/8-16 X 3
2
79
SPLIT
LOCK W
ASHER N/P
3/8”
6
83
U-SHAPE W
ASHER N/P
3/8 ID X 1 1/2 OD X 3/16
2
STEP
5
