11
AP-7000 SERIES LEG PRESS STATION
Assembly List
Item #
Description
Qty
.
7
CABLE
1
33
BLACK NYLON PULLEY
3/8 X 1 1/2 X 4 1/2
1
36
BUTT
ON HEAD SCREW GR-8 N/P
3/8-16 X 2 1/4
1
40
BUTT
ON HEAD SCREW GR-8 N/P
3/8-16 X 1 3/4
2
51
FINISHED HEX NUT
N/P
1/2-13
1
53
FLA
T
W
ASHER SAE N/P
3/8”
4
59
SHOULDER BOL
T
N/P
3/8 X 1 1/8
1
60
NYLON INSER
T
LOCK NUT
N/P
3/8-16
2
61
NYLON PULLEY
3/8 X 1 X 4 1/2 BLACK
1
66
ROD END 1/2-13 (3/8 HOLE)
1
76
SPLIT
BOL
T
GR-8 N/P
1/2-13 X 1
1
77
SPLIT
HEX
T
A
P
BOL
T
GR-8 N/P
1/2-13 X 3 1/2
1
78
SPLIT
LOCK W
ASHER N/P
1/2”
2
86
BLACK NYLON PULLEY
3/8 X 1 X 3 1/2
1
89
NYLON INSER
T
LOCK NUT
N/P
5/16-18
1
STEP
7 LEG EXT/CURL
CABLE
ASSEMBL
Y
89
66
78
7
59
76
89
66
78
7
59
76
51
7
77
78
51
7
77
78
