Page 22
MFT-2700 Multi-Funtional Trainer
Parts List
22
REV0
ItemȱNo. Description
Rev.
PartȱNo.
Qty. ItemȱNo. Description
PartȱNo.
Qty.
1
CABLEȱ
0
UP6792
2
51
LABELȱMFTȬ2700ȱEXERCISEȱCHART
BNH2968
1
2
BOTTOMȱRELEASEȱHANDLE
0
UP6774
2
52
LABELȱMFTȬ2700ȱLEFTȱCAM
BNH2962
1
3
SUPPORTȱHOUSING
0
UP6780
2
53
LABELȱMFTȬ2700ȱLEVELERȱADJUSTMENT
BNH2967
3
4
CHROMEȱLEVERȱHANDLEȱ
0
UP6791
2
54
LABELȱMFTȬ2700ȱRIGHTȱCAM
BNH2961
1
5
ENDȱPULLEYȱBRACKETȱWLM
0
UP6455
2
55
LABELȱMFTȬ2700ȱSCHEDULEȱREPLACEMENTȱPARTS...
BNH2965
1
6
FRONTȱWEIGHTȱSHIELDȱ
0
UP6785
1
56
LABELȱMFTȬ2700ȱSERIALȱ#
BNH2964
2
7
GUIDEȱRODȱ3/4ȱXȱ52ȱ3/8
0
UP6784
4
57
LABELȱMFTȬ2700ȱWARRANTY
BNH2963
1
8
LEFTȱSIDEȱPIVOTȱARMȱ
0
UP6779
1
58
LABELȱNUMBERSȱ10Ȭ200ȱLBS/KGSȱ7/8ȱXȱ3ȱYELLOWȱ&ȱBLACK
BNH4069
2
9
LEFTȱSIDEȱPIVOTȱARMȱSWIVELȱHOUSINGȱ
0
UP6777
1
59
LABELȱTUFFSTUFFȱFITNESSȱ(LGȱVERTICAL)
BNH2933
1
10
LEFTȱSTABILIZERȱ
0
UP6783
1
60
LABELȱWARNING_SERIOUSȱINJURYȱORȱDEATH
BNH2939
1
11
REARȱWEIGHTȱSHIELDȱ
0
UP6786
1
61
LABELȱWEIGHTȱNUMBERSȱREFȱTPȬ10ȱ(200ȱLBS)
ȱȱBNH1542
1
12
RIGHTȱSIDEȱPIVOTȱARMȱ
0
UP6781
1
62
LABELȬCAUTIONȱCHECKȱȱPULLȬPINȱISȱFULLY...
BNH2912
4
13
RIGHTȱSIDEȱPIVOTȱARMȱSWIVELȱHOUSINGȱ
0
UP6778
1
63
LABELȬDANGERȱCHECKȱRETAININGȱNUT...ȱȱ1.5X1.688
BNH2902
4
14
RIGHTȱSTABILIZERȱ
0
UP6782
1
64
LABELȬDANGERȱUSEȱTHISȱEQUIPMENT...ȱ
BNH2903
1
15
SELECTORȱPINȱW/COILȱ3/8ȱXȱ4ȱGOLDȱKNOB
0
UP3035
2
65
LABELȬIMPORTANTȱFORȱSMOOTHȱPERFORMANCE...
BNH2925
2
16
TOPȱPLATEȱDOUBLEȱPULLEYȱBRACKET
0
UP6775
2
66
LABELȬINSPECTIONSȱRECOMMENDEDȱINSPECTION…
BNH2922
1
17
WEIGHTȱSTACKȱFRAMEȱ
0
UP6776
1
67
LABELȬWARNINGȱANCHORȱBOLT…
BNH2990
4
18
BNH1650
38
68
LABELȬWARNINGȱATTENTIONȱUSERS!...
BNH2910
2
19
BNH1982
2
69
LABELȬWARNINGȱATTENTIONȱUSERS!...
BNH2911
2
20
BNH3051
2
70
LABELȬWARNINGȱKEEPȱBODY,ȱHANDS...
BNH2909
2
21
BNH2452
2
71
LABELȬWARNINGȱKEEPȱBODY,ȱHANDS...
BNH2926
2
22
BNH1266
8
72
LEVELER
BNH3052
3
23
BNH0069
4
73
NYLONȱINSERTȱJAMȱLOCKȱNUTȱGRȬ8ȱZ/Pȱ1/2Ȭ13
BNH2997
2
24
BNH2725
4
74
NYLONȱINSERTȱJAMȱLOCKȱNUTȱGRȬ8ȱZ/Pȱ3/8Ȭ16
BNH2998
18
25
BNH3056
2
75
NYLONȱINSERTȱLOCKȱNUTȱZ/Pȱ5/16Ȭ18
BNH2056
4
26
BNH3059
4
76
NYLONȱSTEMȱBUTTONȱ.720ȈȱXȱ.187Ȉ
BNH0533
2
27
BNH0527
8
77
PLASTICȱCAP
BNH2875
1
28
BNH0528
4
78
PLASTICȱINSERTȱSTOPPERȱ1ȈȱRDȱȱ
BNH3054
2
29
BNH0738
4
79
PLASTICȱWASHERȱ25ȱXȱ35ȱXȱ3MM
BNH2726
2
30
BNH2993
4
80
PULLȱPINȱASSYȱ3ȱ1/2ȱCUSTOMȱCUTȱHRDȱSPRING
BNH1723
4
31
BNH2994
2
81
RETAININGȱSNAPȱRINGȱEXT.ȱPLAINȱ.925ȱXȱ1ȱXȱ.042
BNH0419
4
32
BNH2995
10
82
RUBBERȱDONUTȱ3/4ȱXȱ2ȱ1/2
BNH0068
4
33
BNH2033
4
83
SHOULDERȱBOLTȱZ/Pȱ3/8ȱXȱ3/4
BNH2392
8
34
BNH2426
12
84
SINGLEȱSTRANDȱCONNECTINGȱLINKȱ#40
BNH0066
4
35
BNH2996
2
85
SNAPȱLINKȱZ/Pȱ8MMȱXȱ80MM
BNH0065
2
36
BNH2435
2
86
SOCKETȱSETȱSCREWȱZ/Pȱ10Ȭ32ȱXȱ1/8
BNH2088
4
37
BNH1719
4
87
SPLITȱBOLTȱGRȬ8ȱZ/Pȱ1/2Ȭ13ȱXȱ1ȱ(.125ȱRNDȱCUT)
BNH2991
2
38
BNH2738
2
88
SPLITȱLOCKȱWASHERȱZ/Pȱ1/2Ȉ
BNH0572
8
39
BNH3002
1
89
SPLITȱLOCKȱWASHERȱZ/Pȱ3/8Ȉ
BNH2032
8
40
BNH0201
2
90
STRAPȱBRACKETȱ20ȱ#SF20ȱSTAINLESSȱSTEELȱ3/32Ȉ
BNH1904
2
41
BNH2999
1
91
SUPERȱLUBEȱTEFLONȱLUBRICANTȱ82340
BNH0704
2
42
BNH3053
4
92
SWIVELȱHOUSINGȱSTOPPER
BNH3055
2
43
BNH2982
10
93
URETHANEȱBUMPERȱ962
BNH0244
2
44
BNH2031
8
94
UȬSTYLEȱTAPPEDȱHOLEȱNUTȱ1/4Ȭ20
BNH0708
2
45
BNH2030
42
95
RUBBERȱCORRȱMATȱ1/8ȱXȱ3ȱ15/16ȱXȱ24ȱ7/32
BNH3057
2
46
BNH1705
2
96
HEXȱHEADȱCAPȱSCREWȱGRȬ5ȱZ/Pȱ3/8Ȭ16ȱXȱ1
BNH2037
4
47
BNH2258
2
97
HEXȱKEYȱ1/8Ȉ
BNH2541
1
48
BNH2555
4
98
HEXȱKEYȱ3/16Ȉ
BNH2542
1
49
BNH2955
1
99
HEXȱKEYȱ3/32Ȉ
BNH2543
1
50
BNH2936
1
100
HEXȱKEYȱ5/32Ȉ
BNH2545
1
LABELȱMFTȱWEIGHTȱCONVERTIONȱCHART
MFT-2700
Parts List
10ȱLBȱSTEELȱWEIGHTȱPLATEȱBLACKȱ4ȱ9/16ȱXȱ9ȱ7/16ȱASSY
10ȱLBȱTOPȱPLATEȱW/ADJȱSLTRȱBARȱ19ȱBLKȱWTSȱASSY
ALUMINUMȱPULLEYȱ1/2ȱXȱ1ȱXȱ3ȱ1/2
ALUMINUMȱPULLEYȱ3/8ȱXȱ1ȱXȱ2
ALUMINUMȱPULLEYȱ3/8ȱXȱ1ȱXȱ3ȱ1/2
ALUMINUMȱPULLEYȱ3/8ȱXȱ1ȱXȱ4ȱ1/2
BALLȱBEARINGȱ25ȱXȱ47ȱXȱ12MM
BLACKȱACETALȱSTOPPERȱCAPȱ(MFTȬ2700)
YELLOWȱGRIPȱ1/2ȱXȱ4
BRONZEȱBUSHINGȱ1ȱXȱ1ȱ1/4ȱXȱ3/4ȱXȱ1ȱ1/2ȱXȱ1/8
BRONZEȱBUSHINGȱ1/2ȱXȱ5/8ȱXȱ1/2ȱXȱ7/8ȱXȱ1/8
BRONZEȱFLANGEDȱBUSHINGȱ3/8ȱXȱ1/2ȱXȱ1/2ȱXȱ11/16ȱXȱ1/16
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ1/2Ȭ13ȱXȱ1ȱ1/2
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ1/2Ȭ13ȱXȱ3ȱ3/4
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ1/4Ȭ20ȱXȱ3/4
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ3/8Ȭ16ȱXȱ1
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ3/8Ȭ16ȱXȱ1ȱ3/4
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ3/8Ȭ16ȱXȱ2ȱ3/4
BUTTONȱHEADȱSOCKETȱCAPȱSCREWȱGRȬ8ȱZ/Pȱ3/8Ȭ16ȱXȱ3ȱ3/4
CLEVISȱBRACKETȱ3/16ȈȱTHREADȱ8ȱMM
CONTOURȱERGOȱHANDLEȱLONGȱSTRAP
FACILITYȱSIGNȱBEȱALERT!ȱTHEȱFITNESSȱEQUIPMENT...
FINISHEDȱHEXȱNUTȱB/Oȱ1/2Ȭ13
FLANGEȱHEXȱNUTȱ3/8Ȭ16
FLATȱHEADȱSOCKETȱCAPȱSCREWȱZ/Pȱ1/2Ȭ13ȱXȱ3
FLATȱWASHERȱSAEȱZ/Pȱ#12ȱ(1/4Ȉ)
HORIZONTALȱFOOTȱENDȱCAPȱ
LABELȱDANGERȱDOȱNOTȱLEANȱAGAINSTȱORȱPULL...
FLATȱWASHERȱSAEȱZ/Pȱ1/2Ȉ
FLATȱWASHERȱSAEȱZ/Pȱ3/8Ȉ
GASȱSHOCKȱNO.ȱC16Ȭ18868ȱ25ȱ33.94ȱEXT,ȱ16.14ȱSTROKE
HARDȱPVCȱCABLEȱSTOPPERȱ1ȱ1/2ȱRDȱXȱ2
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
