Schreiber Chillers PGD User Manual
Page 2
©
CAREL S
.p
.A.
2003 all r
ights reser
v
ed
Code +302235261 - rel.
1.0 12/09/03
CAREL S.p.A.
Via dell’Industria, 11 - 35020 Brugine - Padova (Italy)
Tel. (+39) 0499 716611 - Fax (+39) 0499 716600
www.carel.com
[email protected]
CAREL reser
ves the r
ight to modify or change its products without pr
ior notice
Keypad LEDs
2 programmable (orange, red)
4 fixed for the back-lighting
Versions available:
PGD0000F00 for built-in installation
PGD0000W00 for wall-mounting
PGD0000F01 for built-in installation
in multiple packaging (20 units)
PGD0000I00 version inserted in pCOI
plastic container
on/off
alarm
enter
menu
I/O
set
prog.
?
info
Graphic
156
202
30
31
18
67
82
43
53
177
Panel mounting
menu
I/O
set
prog.
?
info
Panel
mounting
Panel
mounting
Wall
mounting
Wall
mounting
127
69
154
173
Power supply
from pCO controller
via telephone connector
Operating conditions
-20T60 °C
Storage conditions
-20T70 °C
Index of protection
IP65
Display
Type
FSTN graphic display
Back-lighting
green LED
Resolution
120x32 pixels
Text modes
4 rows x 20 columns
2 rows x 10 columns mixed
Technical specifications
Dimensions (mm) and mounting
