300AC
PARTS LIST
300AC/WC - 460/3 or 230/3
If this unit has special feature(s) installed, see appendix for part number(s).
Part Number Description 460/3 230/3 Qty.
Refrigeration
R105 Compressor – 230/3 – 3 HP 9 1
R106 Compressor – 460/3 – 3 HP 9 1
R122 Condenser – Air Cooled 9 9 1
R123-W Condenser – Water Cooled 9 9 1
R131 Receiver – 1 – 3 Ton 9 9 1
R140-3 Expansion Valve – 3 HW 9 9 1
R141-1 Expansion Valve Flange 9 9 1
R146-1 Refrigeration Sight Glass 9 9 1
R152 Refrigeration Drier – 3/8” 9 9 1
R166 Evaporator (All Copper) 9 9 1
R180 Suction Line Heat Exchanger 9 9 1
R182 High Pressure Switch 9 9 1
R183 Low Pressure Switch 9 9 1
Electrical
E101 Disconnect – 80 Amp 9 9 1
E101-H Disconnect Handle Only 9 9 1
E101-S Disconnect Shaft Only 9 9 1
E103 Contactors – 30 Amps 9 9 2
E104 4 Point Terminal Block 9 9 1
E112 Transformer – 220/3 9 1
E113 Transformer – 440/3 9 1
E115 Grounding Screw 9 9 1
E122 Off/On Switch 9 9 2
E124-3 Pilot Light/Bulb – 24V 9 9 2
E126 Pilot Light Assembly 9 9 2
E132 Thermostat 9 9 1
E134 Dial Thermometer 9 9 1
E145 Fan Motor – ½ HP 9 9 1
E148 Fan Blade – 18” 9 9 1
E153-20 Fan Guard for 18” Blade 9 9 1
Plumbing
P122-S 1 HP Stainless Steel Water Pump 9 9 1
P145-2S Seal & “O” Ring Kit for Water Pump 9 9 1
P149-WSGA Water Sight Glass Assembly 9 9 1
P151-WSG Water Sight Glass Only 9 9 1
P160-2 Stainless Steel Tank – 3 Ton 9 9 1
