MoTeC Appendices 25
Differential Mode Switch
DM Function
off
normal knock sensor connection (default)
on differential sensors
Gain Switches
G2 G1 G0 Gain
On on on 2 (default)
On on off 4
On off on 8
On off off 16
Off on on 16
off on off 32
off off on 64
off off off 128
Knock Centre Frequency Switches
F3 F2 F1 F0 Frequency
off on on on 5 kHz
off on off on 6 kHz
off on off off 7 kHz
off off on on 8 kHz
on off off on 9 kHz
on on on on 10 kHz (default)
on on off on 12 kHz
on on off off 14 kHz
on off on on 16 kHz
