Getting Start with the SK51101 Storage Kit
Thank you for purchasing SK51101! This section covers unpacking and identifying components.
Unpacking and Checking the Contents
The complete SK51101 package includes the following items:
Item Description
Quantity
SK51101 storage cage
1
Hot-swap 2.5” Hard Disk Drive (HDD) tray
1
SATA cable, 700mm
1
HDD failure signal cable, 2P to 2P, 600mm
1
Screw: M3 (4mm) for HDD assembling
4
Screw: M2.5 (4mm) for SK51101 and chassis assembling
4
Technical Specifications
Occupancy
1 x Slim FDD Drive Bay
Capacity
1 x 2.5” SATA Hot-swap HDD
Dimension (WxHxD)
96 x 12.7 x 130 (mm)
3.78 x 0.5 x 5.12 (inch)
Weight 195
g
Compatible CHENBRO Chassis
z RM11704B / RM12404B / RM13204 / RM21508B / RM21706 /RM21804 /
RM31408 / RM31616 / RM41500 / RM51224B / RM51424 / RM51924B
z PC719
