4-Port SATA III Backplane 80H10220919A0 User’s Manual
15F., No.150, Jian 1
st
Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.)
Tel: +886-2-82265500 Fax: +886-2-82265392 Email: [email protected]
www
.chenbr
o.com
Hardware Specification
Specification
Host Interface
SATAIII
HDD Interface
SATA / SAS
Hot-Swap
Yes, allows user to on line replace Hard Disk Drive
Display
LED indicates Hard Disk Drive status ( Defined by Chenbro )
Power LED – Blue ( When HDD is present )
Access LED –Green ( When HDD is busy )
Error LED –Red ( When HDD is fail )
Cooling
3pin Fan connector x2
Connectors
1. SATA III x 4
2. SAS 29pin x 4 ( for HDD )
3. Standard 4pin Power connector x 2 for +5V, +12V from power supply
4. PSU alarm
5. SGPIO
Dimension
114.8 ( Length ) x 107.8 ( Width ) x 2.4 ( Thickness ) mm
Accommodated Chassis
SR105 / SR107 / SR108 / SR209
