8-Port 6Gb/s Mini-SAS Backplane 80H10323604A1
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
5
w
w
w
.
c
h
e
n
b
r
o
.
c
o
m
6Gb/s Backplane Specification
P/N : 80H10323604A1 (Version A0)
Specification
Host Interface MINI-SAS
HDD Interface SAS
Hot-Swap Yes, allows user to on line replace Hard Disk Drive
Display
LED indicates Hard Disk Drive status
Power LED – Blue (When HDD is present)
Access LED – Green (When HDD is busy)
Error LED – Red (When HDD is error)
Cooling Four PWM fan connector
Environment Monitor Temperature sensor detect(RT1, RT2)
Connectors
1.SAS 29P *8
2.MINI-SAS Connector *2
3.Standard 4P Power connector *4 for +5V, +12V from power supply
4. 2P Wafer CONN 2.54mm (1x2) *1
Dimension 425(L) x 54.7(W) x 2.4(H) mm
Material FR4 4 layer
Accommodation Chassis
RM23608
