USER MANUAL
Q - P O W E R S E R I E S P. 8
Q - P O W E R
S E R I E S
.3 The Amplifier
The Q-POWER-series amplifiers offer a power output of:
Q-POWER 4 kW peak per channel @ 4 Ω, using a Bipolar class H (2-step)
high efficiency power amplifier output stage
Q-POWER 6 ,5 kW peak per channel @ 4 Ω, using a Bipolar class H (2-step)
high efficiency power amplifier output stage
Q-POWER 10 2,5 kW peak per channel @ 4 Ω, using a MOSFET class D high
efficiency power amplifier output stage
2 Facilities
The Q-POWER-series amplifiers are fitted with dual voltage Switched Mode
Power Supplies (SMPS), which significantly reduce the weight and size
(only 2U) of the amplifiers. Using SMPS, the symmetrical supply voltages of the
power amplifier are more stable than the power supplies used in conventional
amplifiers.
The dual-voltage feature of the Q-POWER amplifiers senses the mains before
startup and automatically sets the SMPS to the appropriate voltage (20 V or
230 V). No manual voltage setting will be necessary.
2. Q-POWER – The Front
Clip LEDs
2 I-Out LEDs
3 Signal LEDs
4 On LEDs 5 Volume Control Channel A
6 Volume Control Channel B
7 Volume Control Channel C
8 Volume Control Channel D 9 Removable Air Filter System
0 Cooling Air Inlet Vents
On/Off Switch
2 Optional Volume Control Security Cover (included)
