6 SPECIFIC
ATIONS
USER MANUAL
Q - P O W E R S E R I E S P. 23
Q - P O W E R
S E R I E S
Q-POWER 4 Q-POWER 6 Q-POWER 10
THD+N (typical)
20 Hz - 0 kHz, 8 Ω,
dB below rated power
< 0,02 % < 0,03 % < 0,05 %
Damping Factor
8 Ω, kHz and below
>350 > 350 > 600
Maximum output voltage 99 Vp / 98 Vpp 25 Vp / 250 Vpp 45 Vp / 290 Vpp
Input Impedance 5 kΩ balanced
Voltage Gain selectable: 26 dB, 32 dB, or ,4 V input sensitivity
Protection Circuits inrush-current limitation, mains voltage monitoring, temperature monitoring of transformers and heatsinks,
output DC protection, SOA protection, output over current protection,
intelligent mains fuse protection,
Limiter two individually selectable clip limiters for channels A + B and C + D
Fan two temperature dependent speed-controlled axial fans
Indicators LEDs for on, signal/protect, output current and clip
User Interface four individually adjustable volume control knobs for channel A - D
Input Connectors 3-pin XLR connector per channel
3-pin Euroblock connector per channel
Output Connectors two four-pole SPEAKON-connectors and barrier-strip-connector terminals for channel A - D
Dimensions (WxHxD) 483 x 88, x 42 mm (9”, 2U)
Net Weight 0,6 kg 0,6 kg ,5 kg
Shipping Dimensions (WxHxD) 65 x 35 x 540 mm (0,045 m 3 )
Shipping Weight 2,6 kg 2,6 kg 3,5 kg
We reserve the right to make technical alterations without prior notice.
