Camco iD4 TDA302USERGBE - Manual (Page 22)

USER MANUAL
i - S E R I E S
i - S E R I E S
A D V A N C E D A M P L I F I E R S
P.22
6 SPECIFICA
TION
Latency Min. 0,58 ms
Digital inputs AES / EBU, 16 to 24 bit, 44,1, 48, 88,2, or 96 kHz
AC mains
* Approximative mains voltage range where the amplifier can be used.
Amplifier output power performance will decrease with lower mains voltages than the rated 230 V / 220 V / 120 V and slightly
increase with higher mains voltages.
230 V AC, 50 / 60 Hz (for Europe), 190 – 263 V *
220 V AC, 50 / 60 Hz (for China), 190 – 263 V *
120 V AC, 50 / 60 Hz (for US), 95 – 134 V *
Operating temperature +5 °C to +55 °C / +41 °F to +131 °F
Dimensions (W × H × D) 483 Ч 88,1 Ч 419 mm / 19 Ч 3,5 Ч 16,5 inches (19”, 2U)
Net weight 9,4 kg / 20,7 lbs
Shipping dimensions (W × H × D) 600 Ч 105 Ч 527 mm / 23,3 Ч 4,1 Ч 20,7 inches
Shipping weight 11 kg / 24,3 lbs
We reserve the right to make technical alterations without prior notice.
