BatteryMINDer 12248-AA-Series - Manual (Page 8)

BatteryMINDer ®
Aviation-Adjusted Models 12248-AA-S2, S3 & S5
Rev. C-071213 Page 8 P/N VDC12248-AA-Sx-MNL
Common Features (All Models)
1 LED indicators ( a, b & c ) (See Battery Condition and LED Status page)
2 Maintenance Mode ONLY button
3 Temperature Sensor input connector
4 Output cord with quick connect plug
5 Input power cordset
6 Mounting tabs
7 Battery Clip (insulated) BCAA cordset with quick connect plug
8 ATS-1 Ambient Temperature Sensor installed (included)
7
8
2
6
5
6
3
1
a
c
b
AVIATION-CALIBRATED
4
