Page 9
MODEL: PA3801M
Air Hydraulic Pump
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of
location and position in the assembly sequence.
Parts List
Item
Part No.
Description
Qty
1
E05-6-1008-109 Handle
1
2
A67-6-1012-106 Operation Bar
1
3
649-1-0050-055
Screw
3
4
A67-6-1005-109 Control Valve Cover
1
5
601-7-0006-005
Steel Ball
2
6
512-2-0046-104
Compression Spring
2
7
644-1-0060-071
Screw
1
8
649-1-0080-003
Screw
4
9
A67-6-1009-107 Control Valve Base
1
10
A67-6-1006-101 Bearing Washer
2
11
623-6-2542-104
Bearing
1
12
*
O-ring
2
13
A67-6-1003-903 Control Valve
1
14
*
O-ring
1
15
A67-6-1001-202 Oil Outlet Valve
3
16
606-3-0008-101
Spring Washer
3
17
*
Back-up ring
3
18
*
O-ring
3
19
D05-6-1001-106 Nut
2
20
641-1-0098-103
Screw
2
21
A67-6-1011-104 Handle
1
22
*
Pad A
1
23
*
O-ring
2
24
*
Back-up Ring
2
25
A57-6-4002-201 Oil Outlet Valve
1
26
512-2-0043-108
Compression Spring
1
27
601-7-0009-001
Steel Ball
1
28
*
O-ring
3
29
*
O-ring
1
30
649-1-0060-040
Screw
18
31
*
Washer
18
32
A67-6-1017-106 Reservoir Cover
1
33
A67-6-1601-105 Base
1
34
*
Special Washer
2
35
A59-6-1017-102 High Pressure Valve
1
36
A17-6-1216-102 Nail
1
37
512-2-0067-010
Compression Spring
1
38
A17-5-1603-300 Adjust Nut
1
Item
Part No.
Description
Qty
39
601-7-0008-009
Steel Ball
1
40
A57-6-6006-108 Oil Entrance Valve
1
41
520-8-0134-101
Filter
1
42
A57-6-6009-104 Pad
1
43
A57-6-6007-201 Reservoir
1
44
649-1-0060-122
Screw
4
45
A57-6-1002-105 Motor Cover
1
46
A17-6-2105-108 Washer
2
47
A17-4-2100-500 Air Piston
1
48
A57-6-1003-107 Cylinder
1
49
A57-3-1011-108 Piston Assy
1
50
512-2-0410-017
Compression Spring
1
51
A57-6-1014-102 Pump Cover
1
52
A57-6-2023-108 Bush
1
53
*
Back-up Ring
1
54
*
U-cup
1
55
A59-6-1013-105 Pump
1
56
A57-6-1016-106 Washer
1
57
*
Special Washer
1
58
*
Pad B
1
59
512-2-0092-101
Compression Spring
1
60
649-1-0040-007
Screw
1
61
A57-6-5004-109 Air Entrance Cover
1
62
*
O-ring
1
63
A17-6-1105-103 Plastic Cover
1
64
A57-6-2062-108 Adapter
1
65
A57-6-5001-103 Air Entrance Base
1
66
649-1-0050-046
Screw
2
67
A57-6-5003-107 Air Entrance Valve
1
68
*
O-ring
1
69
A67-6-1007-103 Foot Pedal
1
70
666-5-0250-108
C-clip
1
71
A17-6-1002-103 Silencer
1
72
A67-6-1014-100 Valve Base
1
73
649-1-0050-101
Screw
4
74
A57-3-5007-107 Plug
1
75
601-4-0030-095
Spring Pin
1
(*)
A67-3-9903-103 Repair kit
-
(*) indicated items included in, and available only as part of
Seal Kit
9
