BVA Hydraulics HT2005 User Manual
Page 7
7
Item
Part Number for Model:
Description
Qty
HT0405
HT1006
HT1010
HT2005
1
H05-6-2305-107
H10-6-2305-100
H25-6-2305-103 Protective Cap
1
2
H05-5-1103-104
H10-5-1103-107
H25-5-1103-100 Saddle (threaded)
1
3
*
Dust Seal
1
4
H05-6-1804-100
H10-5-1804-103
Threaded Retainer
1
5
649-1-0060-205
Bolt
2
6
*
Special Washer
2
7
N/A
Ram Piston
1
8
H10-5-1204-109
H25-5-1204-102 Bearing
1
9
*
Back-up Ring
1
10
*
U-cup
1
11
H05-4-0145-109
H10-4-0206-106
H10-4-0210-107
H25-4-0205-107 Return Spring Assy.
1
12
N/A
Cylinder
1
13
F040-90009-K04
H02-4-6001-104
Female Coupler
1
14
F040-30007-000
H02-4-6003-108
Dust Cover
1
15
N/A
H02-6-1008-105
Rubber Plug
1
(*)
H05-3-9903-104
H10-3-9903-107
H25-3-9903-100 Repair Kit
-
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
MODELS: HT1006 & HT1010
Single Acting, Threaded
End Cylinders
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Parts List
Note: Not all components of the cylinder are replacement items, but are illustrated as a convenient reference of location
and position in the assembly sequence.
