LED Behavior
Function LED Behavior Description Remark
Power Continuous Illumination Normal Operation Top
(Blue)
Power Unlit Powered off Top
(Blue)
Status Continuous Illumination
1. Connected to switch by
Ethernet or WiFi.
Second (Blue)
Status Unlit
1. Powered off
2. No connection
Second (Blue)
Status Blinking
1. Data Transmission via
WiFi or Ethernet
Second (Blue)
Internet Continuous Illumination Connected to Internet Third (Blue)
Internet Unlit
1. Powered off
2. No connection
Third (Blue)
WPS
Blinking
WPS in progress
WMB SERIES
Fourth (Blue)
WPS
Continuous Illumination
WPS success
WMB SERIES
Fourth (Blue)
Firmware
Upgrade
Blinking Under FW upgrade
Process
MB SERIES
Fourth (Blue)
Firmware
Upgrade
Continuous Illumination Firmware successfully
upgraded
MB SERIES
Fourth (Blue)
