4.2.Capacitance:
An electrostatic capacity capacitance shall be measured at 120Hz by using LCR meter, such as DF2812A
LCR numerical bridge or equivalent.the part shall be clamped at the node .
4.3.Insulation Resistance:
An insulation resistance shall be measured by using an insulation resistance meter,suach as DF2863
insulation resistance meter.
4.1.Resonant Frequency/Resonant Impedance
piezoelectric diaphragm shall be clamped at a node point as shown in following figure to be free from any
mechanical stress,and measured its resonant frequency and resonant impedance by using
YW2788 synthesis parameter test apparatus or equivalent
