Reliability test, Cycles 2 3.4 humidity test, Cycles 10 – BeStar BSP1109-05H1.7 LF User Manual
Page 4
all these tests above should be measured after leaving normal temperature for 2hrs.
3.5 Life test
Rated Voltage with the rated frequency
Duration 1000hrs
3.6 Vibration Test
Vibration Frequency
10~55Hz
Amplitude 1.52mm
Duration 2hrs each of 3 axis
3.7 Drop test
Height 700cm
(to 10mm thickness woodenboard)
Direction 3
3.8 Solderability
Temperature 235 5 C
Duration 3 0.5sec
3.9 Solder Heat Resistance
Temperature 250 10 C
Duration 30sec
Notice: All specification must be satisfied in this condition.
SPL: allowable deviation 5dB of the initial value after testing
