SMT1212-05XH6.5 LF
B
C
D
SMT1212-05XH6.5 LF
1. SMD;thinner , smaller size
2. High S.P.L.; and clear sound
3. Reflowable;RoHS complant
4. Tape & Reel supply
5. Minimum quantity (one reel): 500 pcs.
1.2 Electrical and Mechanical Characteristics
E
F
G
1.Characteristics
1.1 Features
H
E
F
G
H
6 5 4 3 2 1
1.3 Test method:
徐 波
陶红仲
100mm
No reaction in space with in 400mm in all direction
400
mm
Sounder
Standard text Fixture
No Type Specifications
1 Rated Voltage ( V ) 5
2 Operating Voltage ( V) 4-7
3 a)Rated Current (mA) max.30
4 a)Sound Output at 10cm(dB) min.85
5 a)Resonant Frequency( Hz) 2300 300
6 Operating Temperature( C) -40~+85
7 Storage Temperature( C) -40~+90
8 Weight (g ) 2
a)Value applying rated voltage(DC)
Sound Output after reliability test more than 75 dB
博 士 達
王善梅 06/02/17 B
09/08/19
07/08/25 C
change into reel
魏奉玲 09/08/19 D change the height
packing 王善梅
add reflow soldering
curve
