Page 7

7
9. Continued.......
Note: Programming instructions can also be found on interior of lock.
d. Extend the bolt by pressing the “LOCK” button and re-enter the code
to test. The bolt should retract to the unlocked position. If it does not
unlock, repeat steps (a) through (c).
a. Press the program button on the interior unit twice.
b. Enter in 4 to 8 digit code onto the keypad.
c. Press the “LOCK” button to save code.
d.
Programming the 2nd user code.
Extend the bolt by pressing the “LOCK” button and re-enter the code
to test. The bolt should retract to the unlocked position. If it does not
unlock, repeat steps (a) through (c).
Switch #2 Enables the AUTO LOCK
when in the ON position. With Auto Lock
enabled, Keyless Entry Deadbolt will auto-
matically relock the door (extend the bolt)
30 seconds after unlocking.
Switch #1
Status LED blinks every
5 seconds when in the ON position.
Note: The low battery RED LED
cannot be disabled.
CAUTION: Prevent unauthorized entry. This lock can be opened
using two different codes that are randomly set at the factory. Upon
installation and set-up, replace both of these codes with your own.
Since anyone with access to the power board can change these codes,
you must restrict access to the power board and routinely check both
codes to assure they have not been altered without your knowledge.
10. Keyless Entry Deadbolt User Selectable Settings.
Switch #3 Enables the AUDIO sound (Beeper)
when in the ON position. Keypad will now light red/
green when buttons are pressed.
Hint: for easier access, use a ball point pen to operate the switches.
Switch #4 Extra switch with NO FUNCTION.
ON
1
2
3
4
switches
Switch
Position
OFF
ON
LED
Color
Green
Orange
Red
Unlocked
Locked
Low Battery
Lock
Status
Red
Low Battery
