6. FRONT PANEL ASSLY
Reference Part Reference Part
Designator Description DesignationDescription
POT
VR1
5K, WWPOT VR3 500E, WWPOT
VR2 1K, WWPOT VR4 50E, WWPOT
SWITCH
SW1
16A/250V ON/OFF SWITCH
7. MAIN CHASSIS ASSLY
Reference Part
Designator Description
RESISTOR
R1
4.7K/2W, MOR
R2 0.01E / 50W SHUNT
DIODES
CR1
U30D40C (30AMP/400V DUAL DIODE)
CAPACITORS
C1
15000µF / 35V, ELE CAP X 12
C2 1µF / 250V AC CAP X 2
RECTIFIER HEATSINK ASSLY
DIODES
CR1
40HFR20 CR3 40HF20
CR2 40HFR20 CR4 40HF20
SCR1 50A / 800V TT25S12 X 2
FILTER 20A, RFI FILTER
VARISTOR 130V OR 230V TYPE 20D 361
FAN 3 X 12V INNOVATIVE ( HI COOL ) X 3
8. BACK TROUGH ASSLY
Reference Part
Designator Description
FUSE
FUSE1
20Amp, TYPE F ( 115V ) 10 Amp TYPE T ( 230V )
FUSE HOLDER FH0525, 20A / 250V
