Light Tower & Relay Adapter (RMA-LTA-SEN)
AVTECH Software, Inc. Page 2 of 5 AVTECH.com
Light Tower & Relay Adapter Package Contents
• One (1) Light Tower & Relay Adapter ID Box
• One (1) 25' RJ-11 Cord
• One (1) AVTECH International Power Adapter
• One (1) Installation Note (You’re reading it now.)
The Light Tower & Relay Adapter ID Box
Install Your Light Tower & Relay Adapter
Step 1: Connect your Light Tower & Relay Adapter to your Room Alert monitor.
Your Light Tower & Relay Adapter comes with a 25' RJ-11 cable.
1. Connect one end of the RJ-11 cable to the digital port on the Light Tower & Relay
Adapter ID box.
2. Connect the other end to the Light Tower/Relay Switch port on the compatible Room
Alert ID box or digital port on the Room Alert 3E model.
Step 2: Connect your Light Tower & Relay Adapter to a power source.
Your Light Tower & Relay Adapter comes with AVTECH’s International Power Adapter.
1. First connect AVTECH’s International Power Adapter to the power port on the Light
Tower & Relay Adapter.
2. Then plug it into a power source.
Use only AVTECH’s International Power Adapter with AVTECH monitors and
sensors; others could damage your product and will void the warranty.
Do not use the Light Tower & Relay Adapter (LTA) in hazardous (classified)
locations or life/safety applications.
Left Side Front
Relay Port Custom Port
Digital Port Power Port
