Avision AV810C+ User Manual
Page 14
2-6
ADF output paper rack installation
1.
Hold the output paper rack some 30 degrees as shown in Figure
2-5.
2.
Insert the three clasp-joints on the output paper rack in their
respective places on the ADF.
3.
Release the paper rack gently. Make sure the rack is firmly
attached to the ADF.
4.
Pull out the output paper rack extension to the length you
want.
Figure 2-5 Install the ADF output paper rack
ADF Output
Paper Tray
