User’s Manual
v
Table of Contents
1. Introduction ................................................................1-1
2. Installation ..................................................................2-1
2.1 Unlocking the Shipping switch........................2-1
2.1.1 unlocking the scanner ................................2-2
2.1.2 locking the Shipping switch.......................2-3
2.2 SCSI ID ......................................................2-4
2.3 USB Interface ..............................................2-6
2.4 ADF Paper Chute..........................................2-6
2.5 ADF Output Tray ..........................................2-7
2.6 Document Loading .......................................2-8
2.7 ADF Scanning ..............................................2-9
2.8 Connecting the Cable.................................. 2-10
3. Requirements & software installation ....................3-1
3.1 Scanner Driver Installation ............................3-1
3.2 Verifying Your Scanner Installation .................3-3
3.1.1 A Glance of the Scanner Properties Dialog
Box .................................................................3-7
4. Using the Scanner Properties Dialog Box..............4-1
4.1 Buttons on the Scanner Properties Dialog Box ..4-2
4.2 The Image Tab ............................................4-4
4.2.1 The Image Selection Box ..........................4-5
4.2.2 Other Image Options .................................4-7
4.2.3 Scanning color images.............................4-13
4.2.4 Scanning grayscale images ....................4-14
4.2.5 Scanning B&W images.............................4-14
4.2.6 Editing Profiles...........................................4-15
4.3 The Compression Tab ................................. 4-18
4.4 The Color Dropout Tab................................ 4-20
4.4.1 Color Dropout Selection ..........................4-20
