INSTALLATION
A. IDENTIFY 2 DOOR VS. 4 DOOR
1. Because the 2 door and 4 door guards look nearly identical it is important to make sure
you have the correct corner guards for your vehicle type. 2 door and 4 door corner
guards are different, and are not interchangeable. Please take the time to double check
the part numbers on your packaging.
2 DOOR PART #: 10303012AA
4 DOOR PART #: 10303014AA
2. If your parts do not have a very close fit (less than 1-2 mm gaps) please call our technical
support line at 406.251.2100.
B. REMOVAL OF TAIL LAMPS
1. Remove the two inboard Phillips screws and remove tail lamp by carefully sliding the
lamp toward the tail gate.
2. Disconnect the tail lamp wiring harness and set the lamps aside
C. REMOVAL OF TAILGATE HINGE COVERS
1. Using a flat screwdriver, carefully lift each corner of the hinge cover
2. Spread hinge cover and slide outward as shown. Remove and discard covers
