Aeromotive 17245 - H_O CARBURETED FUEL PUMP KIT User Manual
Page 4
1-12. Using the two supplied straight AN-06 hose ends as a guide, measure the length of AN-06 steel braided line needed
to connect the fuel pump assembly outlet to the fuel pressure regulator.
1-13. Cut and assemble the steel braided hose and hose ends as shown in Section 3.
1-14. Using the above steel braided hose assembly, connect one end to the outlet of the fuel pump / filter assembly outlet
and the other to your carburetors fuel feed inlet.
