29
Setting for the start zoom factor
ZOOM END 2~18
Setting for the end zoom factor
ZOOM SPEED LOW: Slow zoom speed
MIDDLE: Medium zoom speed
HIGH: Fast zoom speed
DEFAULT Restores all values in the sub-menu to the factory settings
RETURN Back to main menu
CAMERA SETUP
CAMERA SETUP
EXPOSURE
-
DAY/NIGHT -
WHITE BALANCE -
EFFECT -
RETURN
EXPOSURE
Function Description
ATR-EX NORMAL: Deactivates the WDR function
ATR-EX: Activates the WDR function
LEVEL 0~4
Level 0 is the lowest. At level 4, dark areas are brightened the
most. The higher the level, the more image noise may occur.
SHUTTER 1/50~1/20.000
Fixed setting of exposure time
BLC OFF: Backlight compensation is deactivated
ON: Backlight compensation is activated
AGC -3 dB~28 dB
Setting for the max. amplifier control for poor light conditions
DNR OFF: Noise reduction function is deactivated
1~5: Level 5 is the highest level for noise reduction. The higher
the level, the “softer” or more out of focus the image appears.
DEFAULT Restores all values in the sub-menu to the factory settings
RETURN Back to main menu
DAY / NIGHT
Function Description
MODE AUTO: Automatic switchover between day and night mode.
The switching thresholds are defined in the next menu items.
DAY: Day mode is permanently activated.
NIGHT: Night mode is permanently activated.
EXT: The switching input activates the day or night mode.
DI/DO DI:H
Day mode set for deactivated switching input
DI:L
Night mode set for deactivated switching input
DAY TO NIGHT 0~151
