Technical data
146
Technical data
Subject is to alterations and errors. The dimensions are approximate values.
ABUS digital recorder TVVR35011 TVVR45021
Video compression H.264
Hybrid-compatible -
Camera inputs 8 16
Camera outputs none
Monitor outputs
Monitor: 1 x BNC (1.0 V p- p, 75 Ω), 1 x VGA,
1 x HDMI
Monitor: 1 x BNC (1.0 V p- p, 75 Ω), 1 x VGA,
1 x HDMI
Operating mode Triplex
Resolution (live view)
HDMI:
1920*1080/60Hz(1080P),1600×1200/60Hz, 1280*1024/60Hz,
1280*720/60Hz，1024*768/60Hz
VGA:
1920*1080/60Hz,1600×1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz，1024*768/60Hz
BNC Output:
PAL: 704×576, NTSC: 704×480
Resolution @ frame rate per
camera (recording)
Max. 1920 x 1080p @ 25fps
Total frame rate 200 fps 400 fps
Compression levels Depends on used network camera
Pre-alarm/post-alarm memory 0 –30 sec. / 5–900 sec.
Storage medium 2x SATA HDD 8x SATA HDD
Data backup 3 x USB 2.0
Views 1 / 4 1 / 4 / 6 / 8 / 9 / 16
Recording modes
Manual, schedule, motion detection, alarm, motion detection and alarm,
motion detection or alarm
Search modes By event, date and time
Alarm inputs (NO/NC) 4 16
Alarm outputs 2 (Loading capacity: 12VDC/1A) 4 (Loading capacity: 12VDC/1A)
User levels 2 (max. 31 users)
Network connection 2 x RJ45 10/100/1000 Mbps
Parallel network access 128 camera connections
Network functions Live view, playback, data export, settings
DDNS √
NTP √
PTZ control RS-485
PTZ protocols PELCO-D, PELCO-P, Samsung, LG-MULTIX
Alarms Acoustic warning, OSD signal, e-mail,CMS
Audio
Line In: 1 x BNC (2.0 V p- p, 1000 Ω) – only
for network transmission
Audio Out: 2 x BNC (600 Ω)
Line In: 1 x Cinch (2.0 V p- p, 1000 Ω) – only
for network transmission
Audio Out: 2 x Cinch (600 Ω)
Control USB Mouse, remote control
Software ABUS CMS software
OSD languages German, English, French, Dutch, Danish, Italian, Polish, Czech, Spanish
Power supply 12 VDC, 3.0 A, 50~60 Hz 100~240VAC, 6.3A, 47~63Hz
Power consumption <40W (without HDD) <55W (without HDD)
Operating temperature -10 °C –+55 °C
Dimensions (WxHxD) 470 x 90 x 445 mm
Weight ≤ 8 kg (without HDD)
Certification CE
