AAEON AEC-206 User Manual
Page 18
W a l l m o u n t C h a s s i s
A E C - 2 0 6
Chapter 2 Quick Installation Guide
2-7
2.6 Replacing the filter
You may need to replace the used filter after a period of time.
Please refer to the following charts and procedures.
Remove the two
screws located at the
bottom of the filter cover
then pull the cover free
from the chassis
Remove the filter
and replace it with a
new one.
Insert the filter and
the cover back to the
chassis and screw the
cover through the hole
at the bottom.
