AAEON AEC-206 User Manual
Page 16
W a l l m o u n t C h a s s i s
A E C - 2 0 6
Chapter 2 Quick Installation Guide
2-5
2.4 Adding a Hard Disk Drive
To install a hard disk drive, please refer to the following charts and
procedures.
Unscrew the
mounting bracket from
the chassis.
Insert the hard disk
drive to the mounting
bracket and get it
screwed in the four holes
on the side of the hard
disk.
Attach the
mounting bracket with
the hard disk drive inside
to the chassis with four
screws.
