P I C O - I T X B o a r d P I C O - H D 0 1
Chapter 2 Quick Installation Guide 2-8
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Label
0B0B
Function
CN1 Digital I/O Connector
CN2 COM Port #1
CN3 COM Port #2
CN4 +5V Output For SATA HDD
CN5 SATA Port
CN6 External 12V Input
CN7 RJ-45 Ethernet
CN8 Buzzer
CN9 Audio Line In/Out and MIC Connector
CN10 LPC Expansion I/F
CN11 USB Port #5
CN12 Analog CRT Display Connector
CN13 USB Port #3
CN14 USB Port #4
CN15 18-bit LVDS Output
CN16 USB Port 1 & 2
CN17 HDMI TYPE C
CN18 LVDS Inverter/ Backlight Connector
CN19 Front Panel
