AAEON PICO-HD01 - Manual (Page 11)

P I C O - I T X B o a r d P I C O - H D 0 1
Chapter 1 General Information 1-4
1.3 Specifications
System
 From Factor PICO-ITX
 Processor AMD G-series T40E/ T40R
processor up to 1.0 GHz
 System Memory 204-pin SODIMM DDR3 1066
MHz, up to 4 GB
 Chipset AMD G-series + A50M
 I/O Chipset Fintek F81801U-I
 Ethernet Realtek RTL-8111E,
10/100/1000Base-TX, RJ-45 x 1
 BIOS AMI BIOS-32 Mb ROM
 Wake On LAN Yes
 Watchdog Timer Programmable 255 levels system
reset
 H/W Status
Monitoring Vcore, +1.5V_DDR
 Expansion Interface mSATA/ Mini Card (Half-size) x 1
 Battery Lithium Battery
 Power Requirement DC 12V, AT/ATX (Default)
 Board Size 3.94" x 2.76" (100mm x 72mm)
 Gross Weight 1.7 lb (0.77 Kg)
 Operating
Temperature 32°F~140°F (0°C~60°C)
 Storage Temperature -40°F~176°F (-40°C~80°C)
 Operating Humidity 0% ~ 90% relative humidity,
non-condensing
