AAEON AEC-6930 User Manual
Page 31
E m b e d d e d C o n t r o l l e r
A E C - 6 9 3 0
Chapter 2 Hardware Installation
2 - 13
Step 4: Connect the HDD cable (for IDE Type HDD)
Note: Because the default setting of IDE Drive is Slave (The master was
apply to CFD), when users install the IDE HDD driver in the system, the
HDD will apply to drive Slave.
Connect the HDD cable (for SATA Type HDD)
HDD DISK
SATA Power
W /LO CK
I/O Board Side
