AAEON TKS-G21-CV05 User Manual
Page 35
E m b e d d e d B o x
T K S - G 2 1 - C V 0 5
Chapter 3 AMI BIOS Setup 3-4
2. If the "Control LVDS2 (CH7511)" has been set "Enable," and then, the
screen can be switched to LVDS2 under the OS.
3. This model does not support LVDS2 output under DOS mode. So if it is a
dual LVDS application, users have to enable “Onboard LVDS 2” on the
LVDS1 panel under BIOS interface, and then, enter to the OS.
4. For LVDS1 + LVDS2 application, this model does not support scaling
after entering the OS, users have to set the fixed resolution on their LCD
Panel under BIOS interface, and then, enter to the OS.
