H a l f - s i z e S B C F S B - 9 4 5 G
Appendix C Mating Connector C - 3
ATX1 4P Power
Connnecto
r
Catch
Electronics 1121-700-04S N/A
FAN1 FAN
Connector
Catch
Electronics 1190-700-042 N/A
USB1 USB
Connector
HO-BASE KS-001V-ANW N/A
LAN1(-VE) Ethernet
Connector
BOTHHAND LU1T516-43 LF N/A
LAN1(-G2) Ethernet
Connector
BOTHHAND LA1T109D-D43
LF
N/A
LAN2(-G2) Ethernet
Connector
BOTHHAND LA1T109D-D43
LF
N/A
IR1 IrDA
Connector
JIH VEI
Electronics 21B12050-XXS
10B-01G-4/2.8 N/A
CN4 Mini-Din
PS/2
Connector
CONTEK MAN3061F1G4
01
KB/MS
Cable 1700060192
CN5 KB Pin
Header
HO-BASE 2503-WS-5 N/A
COM1 Serial Port
Box
Header
Catch
Electronics 1147-000-10S Serial Port
Cable
1701260307
COM2 Serial Port
Box
Header
Catch
Electronics 1147-000-10S Serial Port
Cable
1701100305
VGA1 CRT
Display
Connector
Catch
Electronics 3125-000-15SB N/A
CN1 ATX Power
Connector
with BP
Catch
Electronics 1191-700-03S 1703030501
