F u l l - s i z e S B C F S B - 9 4 5 G
Chapter 2 Quick Installation Guide 2 - 8
2.5 List of Connectors
The table below shows the function of each board's connectors:
Label Function
FP1 Front Panel Connector 1
FP2 Front Panel Connector 2
ATX1 4-pin ATX Power +12V Connector
VGA1 VGA Display Connector
FDD1 Floppy Connector
IDE1 EIDE Connector
SATA1~4 Serial ATA Connector
COM1 RS-232 Serial Port Connector
COM2 RS-232/422/485 Serial Port Connector
IR1 IrDA Connector
LPT1 LPT Port Connector
USB2~4 USB x 2 PIN HEADER
USB1 USB Connector
LAN1
10/100 or 100/1000 Base-TX Ethernet
Connector
LAN2 1000 Base-TX Ethernet Connector
DIMM1、2 DDRII Memory Slot
FAN1 4 pin Fan Connector
CN2 AC97 Connector
CN1 ATX Power Control Connector
CN5 Internal Keyboard Connector
CN4 PS2 Keyboard/Mouse Connector
