M i n i - I T X E M B - Q M 6 7
Chapter 1 General Information 1-2
1.1 Introduction
The EMB-QM67 supports Intel
®
Socket G2 (rPGA998B) 2
nd
Generation Intel
®
Core™ i7/i5/Celeron
®
QC/DC processor
which when paired with the Intel
®
QM67 chipset offers a high
performance computing platform with low power consumption.
This new product supports two 204-pin dual-channel DDR3
SODIMM at speeds of 1066/1333/1600 MHz, up to 8 GB.
One CompactFlash™, two SATA 6.0Gb/s and two SATA 3.0
Gb/s interfaces provide ample storages. With dual Gigabit
Ethernet, six COM ports, and eight USB2.0, the EMB-QM67
meets the requirements of today’s demanding applications.
Display requirements are met with an abundance of interfaces
such as CRT, DVI, HDMI, and LVDS. The graphic engine
adopts 2
nd
generation Intel
®
Core™i7/i5/Celeron
®
integrated
Gfx Gen 5.75 graphics to offer high definition display function.
With all of its integrated features, the EMB-QM67 strikes a
balance of performance and price. This versatile product targets
Industrial Automation, Entertainment, Networking, KIOSK/POS,
Transportation, Banking, Healthcare and Digital Signage
applications that require high performance and high reliability.
