Chapter 2 Quick Installation Guide 2 - 11
3 Digital- IN/OUT (Port1 Bit 4) 4 Digital- IN/OUT (Port3 Bit 4)
5 Digital- IN/OUT (Port3 Bit 5) 6 Digital- IN/OUT (Port3 Bit 6)
7 Digital- IN/OUT (Port3 Bit 7) 8 Digital- IN/OUT (Port6 Bit 3)
9 +3.3V 10 GND
The pin definitions and registers mapping are illustrated below:
Address: A00H
4 in / 4 out
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6 Pin7 Pin8
GPI 11 GPI 12 GPI 14 GPI 34 GPO
35 GPO
36 GPO
37 GPO
63
8 in
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6 Pin7 Pin8
GPI 11 GPI 12 GPI 14 GPI 34 GPO
35 GPO
36 GPO
37 GPO
63
8 out
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6 Pin7 Pin8
GPI 11 GPI 12 GPI 14 GPI 34 GPO
35 GPO
36 GPO
37 GPO
63
2.13 SATA Power (PWR1~PWR2)
Pin Signal
1 +12V
2 GND
3 GND
4 +5V
2.14 Front Panel Connector (CN4)
Pin Signal Pin Signal
1 Power On Button (-) 2 Power On Button (+)
