System – AAEON ETX-701 User Manual
Page 11
E T X C P U M o d u l e
E T X - 7 0 1
Chapter 1 General Information
1 - 4
1.3 Specifications
System
CPU
AMD Geode LX800 (500MHz)/ LX900
(600MHz) Series Processors
Memory
One DDR SODIMM, supports non-ECC
DDR 333 up to 1GB or DDR 400 up to
512MB
Chipset AMD
CS5536
Ethernet
Realtek RTL8139DL(M)/ Intel 82551QM
(S) (Co-lay), 10/100Base-TX
BIOS
PLCC type, 1MB ROM
Note: If the space of the module is not enough, please consider to use TSOP
BIOS chip. The P/N of TSOP BIOS is 14S6200802.
EEPROM
Save BIOS data
Note: Please check the address of EEPROM.
Watchdog Timer
Winbond W83627HG-AW (14S4362704)
Generates a Time-out System Reset
H/W Status Monitoring
Winbond W83627HG-AW (14S4362704)
Supports Power Supply Voltages, Fan
Speed and Temperatures Monitoring
Wake on LAN
Yes
OS Support
Windows 32-bit XP Pro
Windows XP Embedded
WinCE5.0/6.0
