Chapter 3 CPU, Heatsink and Fan Installation
3-7
b. Viewing the board again from the topside make sure
the bracket on the solder side has not shifted from
its position. Daub thermal compound on the CPU.
c. Place the Heatsink on the top of CPU. Please make
sure that the four screws are aligned with the holes
on the board.
