S u b C o m p a c t B o a r d G E N E - 9 3 1 0
Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector Connect
or Label
Function
Vendor Model no
Available
Cable
Cable P/N
CN2 Digital I/O
Connector
CATCH 2.00mm Pitch 10
pins ( CATCH
H754-2x5 or
compatible)
Digital I/O
Cable
N/A
CN3 TV-Out
Connector
CATCH 2.00mm Pitch 8
pins ( CATCH
H754-2x4 or
compatible)
TV-Out
Cable
1700080180
CN6 Audio
Connector
CATCH 2.00mm Pitch 14
pins ( CATCH
H709-2 or
compatible)
Audio
Cable
1700140510
CN9 COM2
Connector
CATCH 2.00mm Pitch 10
pins ( CATCH
H754-2x5 or
compatible)
Serial Port
Cable
1701100206
CN12 LVDS(1)-L
CD
Connector
CATCH 1.25mm Pitch 30
pins ( CATCH
H716 or
LVDS
Cable
N/A
