2.12 LCD Backlight +5V/+12V Selection (JP9)
JP9 Function
1-2 +12V
2-3 +5V (Default)
2.13 Digital I/O Connector (CN2)
This connector offers 4-pair of digital I/O functions and address is 801H. The
pin definitions are illustrated below:
Pin Signal Pin Signal
1 DIO1-1 2 DIO1-2
3 DIO1-3 4 DIO1-4
5 DIO1-5 6 DIO1-6
7 DIO1-7 8 DIO1-8
9 +5V 10 GND
The pin definitions and registers mapping are illustrated below:
Address: 801H
BIOS
Setting Connector
Definition
Address IT8712F/ KX GPIO Setting
DIO1-1 CN2 Pin1 Bit0 U4 Pin27 (GPIO20)
DIO1-2 CN2 Pin2 Bit1 U4 Pin26 (GPIO21)
DIO1-3 CN2 Pin3 Bit2 U4 Pin25 (GPIO22)
DIO1-4 CN2 Pin4 Bit3 U4 Pin24 (GPIO23)
DIO1-5 CN2 Pin5 Bit4 U4 Pin23 (GPIO24)
DIO1-6 CN2 Pin6 Bit5 U4 Pin22 (GPIO25)
DIO1-7 CN2 Pin7 Bit6 U4 Pin21 (GPIO26)
