13 PCIE_CLK 14 UIM_RESET
15 Ground 16 UIM_VPP
17 N/C 18 Ground
19 N/C 20 W_DISABLE#
21 Ground 22 PCIE_RST#
23 PCIE_RXN 24 +3.3 Volt. Standby
25 PCIE_RXP 26 Ground
27 Ground 28 +1.5 Volt.
29 Ground 30 SMBCLK
31 PCIE_TXN 32 SMBDATA
33 PCIE_TXP 34 Ground
35 Ground 36 USB_Data-
37 Ground 38 USB_Data+
39 +3.3 Volt. Standby 40 Ground
41 +3.3 Volt. Standby 42 N/C
43 Ground 44 N/C
45 N/C 46 N/C
47 N/C 48 +1.5 Volt.
49 N/C 50 Ground
51 N/C 52 +3.3 Volt. Standby
2.43 CompactFlash Disk (CFD1)
Pin Signal Pin Signal
1 Ground 26 Ground
2 PDD3 27 PDD11
3 PDD4 28 PDD12
4 PDD5 29 PDD13
5 PDD6 30 PDD14
