2.40 CRT Display Connector (CN30)
Pin Signal Pin Signal
1 RED 2 GREEN
3 BLUE 4 N/C
5 GREEN 6 Ground
7 Ground 8 Ground
9 +5 Volt. 10 CRT_PLUG#
11 N/C 12 DDCDATA
13 HSYNC 14 VSYNC
15 DDCCLK
2.41 COM Port 1 Connector (CN31)
Pin Signal Pin Signal
1 DCDA 2 RXA
3 TXA 4 DTRA
5 Ground 6 DSRA
7 RTSA 8 CTSA
9 RIA
2.42 Mini-Card Slot (CN32)
Pin Signal Pin Signal
1 PCIE_WAKE# 2 +3.3 Volt. Standby
3 N/C 4 Ground
5 N/C 6 +1.5 Volt.
7 N/C 8 UIM_PWR
9 Ground 10 UIM_DATA
11 PCIE_CLK# 12 UIM_CLK
