S u b C o m p a c t B o a r d G E N E - Q M 8 7
Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector Connector
Label
Function
Vendor Model no
Available
Cable
Cable P/N
CN1
External +5VSB
Power Input and
PS_ON#
JST XHP-3 ATX Cable 170220020B
CN2
2
nd
LVDS
Inverter
JST PHR-5
Invertor Cable 1705050153
CN3
+5V Output for
SATA HDD using
JST PHR-2
2 Pins For
SATA Power
1702150155
CN4
+5VSB Output w/
SMBus
JST PHR-6
ATX External
5VSB Cable
External AUX
Power and
PS_ON#
CN5
CPU Fan
Connector
Molex 22-01-2035 N/A N/A
CN6 SATA Port 2 Molex 887505318 SATA Cable 1709070500
CN7 SATA Port 1 Molex 887505318 SATA Cable 1709070500
CN8
External 12V
Input
Molex
19211-0003 Power Cable
170204010R
CN9 Digital I/O Molex 51110-1050 N/A N/A
CN10 1
st
LVDS Inverter JST PHR-5 Invertor Cable 1705050153
