P C / 1 0 4 M o d u l e P F M - H D S
Chapter 2 Quick Installation Guide 2-8
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Label Function
CN1 CRT Connector
CN2 Audio Connector
CN3 LVDS Backlight Connector
CN5 Internal LVDS Connector
CN7 LAN Connector
CN8 BIOS Connector
CN10 Battery Connector
CN11 USB2.0 Connector
CN12 USB2.0 Connector
CN13 USB2.0 Connector
CN14 USB2.0 Connector
CN15 PCI104 Connector
CN18 CFast Connector
CN19 SATA Power Connector
CN20 SATA Connector
CN22 COM1 RS232 Connector
CN23 COM3 RS232 Connector
CN24 COM4 RS232 Connector
CN25 COM2 RS232/422/485 Connector
CN27 Digital I/O Connector
