E P I C B o a r d E P I C - Q M 5 7
Chapter 2 Quick Installation Guide 2-12
Clear CMOS (JP4-1)
JP4-1 Function
1-3 Protected (Default)
3-5 Clear
Clear ME ROM (JP4-2)
JP4-2 Function
2-4 Protected (Default)
4-6 Clear
2.10 Touch Panel 4/5/8-wire Mode Selection (JP5)
JP5 Function
1-2 (Open) 5 Wire
1-2 (Close) 4 & 8 Wire (Default)
2.11 COM2 RI/+5V/+12V Selection (JP6)
JP6 Function
1-2 +12V
3-4 RI
5-6 +5V (Default)
2.12 AT/ATX Power Mode Selection (SW1)
SW1 Function
1(ON), 2(OFF) ATX Power
1(OFF), 2(ON) AT Power (Default)
2.13 Front Panel Connector (CN1)
Pin S i g n a l Pin S i g n a l
1 Power On Button (+) 2 Power On Button (-)
